| UL Style No.4389 | | 多芯鐵氟龍硅膠護套高溫電線 | | Multiple-Conductor, Tefulon Insulated Wire | | 產品描述 PRODUCT DEION | | 額定電壓Nominal Voltage:600Vac | | 溫度范圍Temperature Range:-60℃～+200℃ | | 導體Conductor:30～10AWG Tinned | | 絕緣體Insulation:FEP | | 外被Jacket:Silicone | | 顏色:紅-黑-藍-棕-黃-綠-橙-灰-白-黃綠等 | | Colour: Red-Black-Blue-Brown-Yellow-Green-Orange-Gray-White-Yellow/Green,etc. | | 適用范圍APPLICATION | | 適用于家用電器,新能源汽車,照明燈具,電子設備,溫度傳感器,航天航空,軍工產品,冶金化工,通訊,汽車船舶,電力安裝等連接. | | Applies to household appliances, new energy vehicles, lighting lamps and lanterns, electronic equipment, temperature sensor, aerospace, military products, metallurgical chemical industry, communication, car shipping, electrical installation and other connections. | | | | | | | | | | | | | | 導體
Conductor | 絕緣體
Insulation | 電氣特性
Elecrical Characteristic | 包裝
Packing | AWG
Core number | 導體結構
No.xΦmm | 絞合
外徑
mm | 絕緣
厚度
mm | 芯線
外徑
ID | 外被
厚度
mm | 完成
外徑
OD | 導體
電阻
Ω/1000ft | 耐電壓
Dielectric Strength AC
1 min | 米/卷
Mt/coils | | 12*2C | 19 | X | 0.47 | 2.35 | 0.51 | 3.35 | 1.14 | 9.00 | 5.64 | 2000V | 305/610 | | 12*3C | 19 | X | 0.47 | 2.35 | 0.51 | 3.35 | 1.14 | 9.50 | | 12*4C | 19 | X | 0.47 | 2.35 | 0.51 | 3.35 | 1.14 | 10.40 | | 12*5C | 19 | X | 0.47 | 2.35 | 0.51 | 3.35 | 1.14 | 11.35 | | 14*2C | 19 | X | 0.37 | 1.85 | 0.51 | 2.85 | 1.14 | 8.00 | 8.96 | | 14*3C | 19 | X | 0.37![]() | 1.85 | 0.51 | 2.85 | 1.14 | 8.45 | | 14*4C | 19 | X | 0.37 | 1.85 | 0.51 | 2.85 | 1.14 | 9.20 | | 14*5C | 19 | X | 0.37 | 1.85 | 0.51 | 2.85 | 1.14 | 10.00 | | 16*2C | 19 | X | 0.30 | 1.50 | 0.51 | 2.50 | 1.14 | 7.30 | 14.6 | | 16*3C | 19 | X | 0.30 | 1.50 | 0.51 | 2.50 | 1.14 | 7.70 | | 16*4C | 19 | X | 0.30 | 1.50 | 0.51 | 2.50 | 1.14 | 8.35 | | 16*5C | 19 | X | 0.30 | 1.50 | 0.51 | 2.50 | 1.14 | 9.05 | | 18*2C | 19 | X | 0.24 | 1.18 | 0.51 | 2.20 | 1.14 | 6.70 | 23.2 | | 18*3C | 19 | X | 0.24 | 1.18 | 0.51 | 2.20 | 1.14 | 7.05 | | 18*4C | 19 | X | 0.24 | 1.18 | 0.51 | 2.20 | 1.14 | 7.60 | | 18*5C | 19 | X | 0.24 | 1.18 | 0.51 | 2.20 | 1.14 | 8.25 | | 20*2C | 19 | X | 0.19 | 0.95 | 0.51 | 1.95 | 1.14 | 6.20 | 36.7 | | 20*3C | 19 | X | 0.19 | 0.95 | 0.51 | 1.95 | 1.14 | 6.50 | | 20*4C | 19 | X | 0.19 | 0.95 | 0.51 | 1.95 | 1.14 | 7.00 | | 20*5C | 19 | X | 0.19 | 0.95 | 0.51 | 1.95 | 1.14 | 7.55 | | 22*2C | 19 | X | 0.15 | 0.75 | 0.51 | 1.75 | 1.14 | 5.80 | 59.4 | | 22*3C | 19 | X | 0.15 | 0.75 | 0.51 | 1.75 | 1.14 | 6.05 | | 22*4C | 19 | X | 0.15 | 0.75 | 0.51 | 1.75 | 1.14 | 6.50 | | 22*5C | 19 | X | 0.15 | 0.75 | 0.51 | 1.75 | 1.14 | 7.00 | | 24*2C | 7 | X | 0.20 | 0.60 | 0.51 | 1.60 | 1.14 | 5.50 | 94.2 | | 24*3C | 7 | X | 0.20 | 0.60 | 0.51 | 1.60 | 1.14 | 5.75 | | 24*4C | 7 | X | 0.20 | 0.60 | 0.51 | 1.60 | 1.14 | 6.15 | | 24*5C | 7 | X | 0.20 | 0.60 | 0.51 | 1.60 | 1.14 | 6.60 | | 26*2C | 7 | X | 0.16 | 0.48 | 0.51 | 1.50 | 1.14 | 5.30 | 150 | | 26*3C | 7 | X | 0.16 | 0.48 | 0.51 | 1.50 | 1.14 | 5.50 | | 26*4C | 7 | X | 0.16 | 0.48 | 0.51 | 1.50 | 1.14 | 5.90 | | 26*5C | 7 | X | 0.16 | 0.48 | 0.51 | 1.50 | 1.14 | 6.35 | | 28*2C | 7 | X | 0.12 | 0.36 | 0.51 | 1.35 | 0.38 | 3.50 | 239 | | 28*3C | 7 | X | 0.12 | 0.36 | 0.51 | 1.35 | 0.38 | 3.70 | | 28*4C | 7 | X | 0.12 | 0.36 | 0.51 | 1.35 | 0.38 | 4.05 | | 28*5C | 7 | X | 0.12 | 0.36 | 0.51 | 1.35 | 0.38 | 4.45 | | 30*2C | 7 | X | 0.10 | 0.30 | 0.51 | 1.30 | 1.14 | 4.90 | 381 | | 30*3C | 7 | X | 0.10 | 0.30 | 0.51 | 1.30 | 1.14 | 5.10 | | 30*4C | 7 | X | 0.10 | 0.30 | 0.51 | 1.30 | 1.14 | 5.45 | | 30*5C | 7 | X | 0.10 | 0.30 | 0.51 | 1.30 | 1.14 | 5.80 | | | | | | | | | | | | | | ![]() | | | | | | | | | | | | | | | | | | | | | | | | |
|
