型號Model

CH-TS-MX5B-600

螺桿直徑Screw diameter

￠40/35/45/50/40mm

螺桿長徑比Screw long diameter ratio

30 : 1

螺桿轉速Screw speed

15-90r/min

膜泡冷卻方式Membrane bubble cooling method

水冷 water cooling

適用原料Applicable raw materials

PP、PE、LLDPE、MLLDPE、HV

膜層The layer of die head

2/5layer

溫度控制器temperature controller

PID+SSR/ PID +SCR

旋轉裝置/振動裝置rotary device + oscillating device

yes

背靠背絡筒機back to back winder

Auto change roller

內冷系統IBC

yes

糾偏EPC

Made in hyfil

主電機功率Main motor power

7.5/7.5/11/15/7.5kw

**大擠出量Maximum extrusion

110Kg/h

模頭規格Die head specifications

￠220

薄膜厚度單面Thickness single surface

0.045-0.20mm

膜厚薄偏差Film thickness bias

+7%

薄膜**大折徑Film maximum folding diameter

600mm

總功率Total power

110Kw

外形尺寸Overall dimensions

6600x3800x4660mm

機器重量Machine weight

10T
